ZeroAir 5/20
Zero Air Generator
DESCRIPTION
The ZeroAir is available in both 5 and 20 L/min, and can be installed on a workbench or wall. It is excellent for FID and FPD and guarantees a clean base line with no fluctuations. Platinum Palladium HC system completely removes HCT, leaving less than 0.1 ppm, for an absolutely stable, noise-free baseline. The ZeroAir features a catalyzer temperature indicator. It is ready to be connected to a dedicated AirComp compressor, and can be adapted to support between 14 and 55 FID.
Versatile Installation
Dual benchtop or wall-mounting installation options
Plug and Play
Comes ready to be connected to a dedicated AirComp compressor.
Parallel Connection
Connect up to four stacked generators in a tower configuration.
Palladium-Platinum HC System
Ensures 100% removal of hydrocarbons with HCT at <0.1ppm for applications with high sensitivity detectors.
STANDARD FEATURES
- Modular configuration
- Claind's PSA Technology
- Easy, "plug and play" integration with the dedicated Brezza series air compressor AirComp
- UHP Zero Air with CO2 at < 1 ppm and THC at < .1 ppm. The optimal solution for TOC Analyzers!
- Platinum Palladium HC system for HCT integral removal to less than .1 ppm for a stable and interference free baseline
- CPU with Touch Screen Display (connectable with CAN BUS) allows you to monitor the operational status
- CPU also has an Ethernet output for PC connection
SPECS
| Instrument Name | ZeroAir 5/20 | |
| Flow Rate |
ZeroAir 5: 5 L/min +/- 10% at 2000 meters above sea level ZeroAir 20: 20 L/min +/- 10% at 2000 meters above sea level |
|
| Technology Employed | Platinum-Palladium Catalytic Reactor | |
| Efficiency | Total Residual Hydrocarbons with Catalyzer: < 0.1 ppm | |
| HC Removal Efficiency |
Methane > 99 % Aromatics (BTX) and Hydrocarbons (starting from C3HN) > 99.5% CO, H2, Ethylene, and Propylene > 99.9 % |
|
| Output Pressure |
0 - 145 PSI 0 - 10 bar |
|
| Air Input Characteristics | Particulate ≤ 0.01 mm Oil vapors ≤ 0.01 mg/m^3 Moisture ≤ -15°C dew point ATP |
|
| Electrical Supply |
ZeroAir 5: 115/230 V ZeroAir 20: 115/230 V |
|
| Protection Index | IP20 | |
| Operating Temperature | 41 °F - 95 °F (5°C - 35°C) | |
| Environmental Humidity | max 80% without condensation | |
| Maximum Altitude |
2000 meters above sea level 6561.68 feet above sea level |
|
| Dimensions |
Height: 13.8" (35cm) Width: 7.9" (20cm) Depth: 6.3" (16cm) |
|
| Weight |
ZeroAir 5: 15 lbs (7kg) ZeroAir 20: 20lbs (9kg) |
|
| Pneumatic Connections |
Compressed air inlet: G 1/8" female Purified air output: G 1/8" female |
|
| Warranty |
2 years |
|
ACCESSORIES
-
AirComp oil free compressor
- Maintenance kit
